Retail Pack Slicer I-Slice 3400

High accuracy and utilization

The I-Slice 3400 slices, and batches salmon and smoked salmon to fit every pack’s size and weight. The salmon fillets are first weighed and scanned to calculate optimal utilization. Each slice is then cut to match the defined target weight, and the slices are aligned in accurate batches in accordance with the pack size.

Maximum flexibility

The standard edition cuts salmon slices with an angle interval of 8°-40°. To create high angle products such as portions, we offer the upgraded edition with an angle interval of 8°-72°. The slicer can place the batches on boards and trays in all standard retail sizes or go straight from the belt to the packing unit.

Hands-free handling

The slices in each batch are perfectly aligned for exceptional pack presentation and spaced to match the board size automatically. Combining these features and the high accuracy on weight and count eliminates the need for manual handling.

Capacity	Up to 90 kg/h*
Line capacity	App. 360 kg/h* (with 4 slicers)
Cutting angle	8°-40°   / Optional 8°-72°
Max cutting width	1 x 250 mm
Max product length	750 mm
Max product height	Up to 60 mm
Max slice length	200 mm
Slice thickness	2-20 mm
Batch size	2-50 slices   / up to 1000 g
Product temperature	0 °C +- 4 °C
Electricity	3x400V + N + PE / 3x220V + PE
Power consumption	3.3 kW
Compressed air	50 l/min. min. 8 bar pressure
Dimensions L x W x H	3330 x 1380 x 1610 mm
Weight	1050 kg

* Depending on batch configuration

Board/tray size

Min./max length	90-460 mm
Min./max width	65-250 mm
Max depth trays	40 mm



Standard 8°-40° cutting angle interval

Upgrade 8°-72° cutting angle interval

SmartBase

The internal SmartBase software provides real-time and historical data on machine health and production performance, including throughput, product and trim weights, along with technical insights like sensor run time, calibration data, key temperatures and active alarms.

SmartBase's remote capabilities allow fast issue resolution and support from JBT Marel’s service engineers.
